SABER Certified PSA Nitrogen Generator for Laser Cutting 5-5500Nm3/hr
Λεπτομέρειες:
| Place of Origin: | China |
| Μάρκα: | KERONG GAS |
| Πιστοποίηση: | ISO9001, CE, ASME |
| Model Number: | KRN |
Πληρωμής & Αποστολής Όροι:
| Minimum Order Quantity: | 1 pc |
|---|---|
| Τιμή: | negotiable |
| Packaging Details: | Wooden box |
| Delivery Time: | 8 weeks |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000pcs per year |
|
Λεπτομερής ενημέρωση |
|||
| Name: | Nitrogen Generator For Laser Cutting | Purity: | 90%~99.9999% |
|---|---|---|---|
| Dew point: | -45℃ or more | Material: | Stainless steel or carbon steel |
| Capacity: | 5Nm3/hr~5500Nm3/hr | Pressure: | Adjustable |
| Επισημαίνω: | high temperature resistant nitrogen generator,PSA nitrogen generator for laser cutting,SABER certified nitrogen gas generator |
||
Περιγραφή προϊόντων
| Attribute | Value |
|---|---|
| Name | Nitrogen Generator For Laser Cutting |
| Purity | 90%~99.9999% |
| Dew point | -45℃ or more |
| Material | Stainless steel or carbon steel |
| Capacity | 5Nm3/hr~5500Nm3/hr |
| Pressure | Adjustable |
Our SABER Certified High Temperature Resistant Nitrogen Generator for Laser Cutting is engineered for reliable performance in hot climates while delivering nitrogen purity up to 99.99%. Certified under the SABER conformity system, it meets Saudi Arabian safety and quality standards. Using advanced Pressure Swing Adsorption (PSA) or membrane technology, it produces continuous, on-site nitrogen at stable pressure and purity, ensuring oxidation-free, high-quality laser cuts. Designed with enhanced cooling and heat-resistant components, it operates efficiently even in ambient temperatures above 45°C. With automatic operation, low maintenance, and energy efficiency, this generator ensures dependable nitrogen supply for demanding laser cutting environments.
| Model | Nitrogen flow rate(Nm3/hr) | Purity(%) | Air need(m3/min) | Net dimensions(mm) |
|---|---|---|---|---|
| KRN159 | 7 | 99 | 0.33 | 1200*600*1900 |
| 6 | 99.5 | 0.32 | ||
| KRN219 | 15 | 99 | 0.7 | 1200*600*1900 |
Note: Complete technical table with all models available upon request.
- Online monitoring of oxygen purity, pressure, flow rate and dew point.
- Unqualified oxygen sound and light alarm, long time alarm automatic stop, unqualified automatic oxygen emptying.
- Air dryer and air filters automatic drainer discharge.
- Automatic warning of spare parts replacement.
- Remote control / fully automatic
- Molecular sieve automatic compaction
- Pneumatic valve switching by programmable controller automatic control
- The IPC, DCS, the specific configuration of other specific programs
A: We are a factory with over 20 years industrial experience.
A: Yes, we can customize it as your request.
A: About 60~90 days after receiving deposit.
A: We have ASME, CE, ISO9001-2015, ISO13485 for medical oxygen generator. And we can apply for specific certificate for different country such as SONCAP for Nigeria, SASO for Saudi Arabia, etc.
A: Beyond warranty period (For 12-Months against any manufacturing defect from the date equipment acceptance after commissioning or 18-months from the time of the delivery whichever comes first), supplier will provide spare parts, accessories, easily damaged parts via preferential price.
A: Pre-sales service, in-sales service, after-sales service. If you become our local distributor, we can introduce end-customers to purchase from you.
A: Qingdao port or Tianjin port. And we can arrange to deliver Guangzhou, Shanghai, Urumqi, or other Chinese cities, too.
A: We can do as your request.
